ECO Series:
Bio-based TPU ECO Series
Features: Excellent Mechanical Properties, Wear Resistance, Good Low Temperature Flexibility, Excellent Processing Flow and Rapid Prototyping.
Quantity:
Processing method: Injection, Extrusion
Applications: Shoe, Film, Roller, Auto Parts, Blending Modification, Injection Parts, etc.
性能 Properties | 标准 Standard | 单位 Unit | ECO-12565 | ECO-12575 | ECO-14085 | ECO-13790 | ECO-11595 | ECO-87560 | ECO-86575 | ECO-86085 | ECO-84095 |
密度 Density | ASTM D792 | g/cm3 | 1.18 | 1.18 | 1.16 | 1.17 | 1.18 | 1.11 | 1.14 | 1.15 | 1.17 |
硬度 Hardness | ASTM D2240 | Shore A/D | 65A | 75A | 85A | 90A | 95A | 65A | 80A | 85A | 95A |
生物基含量 Biobased Content | ASTM D6866 | W/W % | 25 | 25 | 40 | 37 | 15 | 75 | 60 | 60 | 40 |
抗张强度 Tensile Strength | ASTM D412 | MPa | 25 | 30 | 35 | 38 | 41 | 28 | 26 | 28 | 35 |
断裂伸长率 Elongation at Break | ASTM D412 | % | 750 | 650 | 540 | 500 | 450 | 750 | 550 | 500 | 450 |
撕裂强度 Tear Strength | ASTM D624 | kN/m | 60 | 75 | 95 | 105 | 130 | 65 | 75 | 80 | 125 |
磨耗 DIN Abrasion Loss | ISO 4649 | mm3 | 75 | 60 | 48 | 43 | 40 | 80 | 80 | 70 | 45 |
加工温度 Processing Temperature | -- | ℃ | 185-195 | 175-185 | 195-205 | 200-210 | 205-215 | 180-200 | 160-180 | 185-200 | 200-215 |
